When placing tiles, Innoplus places the tile over the whole surface area. However, you may want different tiles on the same area, for example to have a different tile feature on a wall just for the shower enclosure.
You can make exact cuts into the tiles placed on the wall by using the Internal wall at wall tool, and then deleting the new internal wall. Once complete, there is space to place a different tile.
Take the following steps:
- Drag the first tile onto the surface area that you want to cover most of the wall.
- Click the Build tab and select the Internal wall at wall icon in the toolbar.
-
Hover over the wall that you want to place a second tile. The wall will highlight as a blue grid.
-
Click the wall.
- In the Internal wall at wall option, adjust the sliders as appropriate or enter specific measurements.
- Click OK.
- The internal wall is placed. While the new wall is still selected, hit the delete key on your keyboard.
- The original tile on the wall has now been cropped. Drag the second tile in the new space created on the wall.
